KTA38-G4

New Cummins Diesel Engines

Engine Brand Cummins
Engine Models KTA38-G4
Rated Power 1007kW(1350HP)@ 1800rpm / 1112kW(1490HP)@ 1800rpm(Standby Power)
Peak Torque
Fuel Pumping System PT Pump Direct Injection
Emission Standard Tier/Euro II
Tail Gas Retreatment
Cummins diesel engine KTA38-G4 technique specification
Egnine Cylinder Type 12 Cylinders, V Type
Bore and Stroke 159 mm* 159mm
Compression Ratio 15:1
Displacement Type 37.8 L
Fuel Consumption 274L/hr / 301L/hr(Standby)
Air Intake Method Type Turbochager&Intercooled
Engine Size 2341mm*1360mm*1653mm
Weight Net 3723 Kg
Cummins diesel engine KTA38-G4 trade information
Warranty Time Basically 1 year or 1500 Hours, please check our warranty terms
Delivary Port Shanghai or any China port
Leading Time 15 working days
Trade Termes FOB/CIF/CNP
Payement termes T/T, L/C

Certificate of Conformity, Operation and Maintenance Manual, Notice and nameplate etc.

Additional files for automobile engine: Rubbing paper for license plate application.

Additional files for marine engine: Certificate CCS/IMO

Yes, normally all the genuine parts are under the warranty from the brand owner, in some cases, we offer a warranty under our own company, but this warranty covers only the goods, not the service.
