KTTA50-C1600

New Cummins Diesel Engines

Engine Brand Cummins
Engine Models KTTA50-C1600
Rated Power 1195kW/1600 HP @ 2100 rpm
Peak Torque 4400 lbs. [email protected] rpm
Fuel Pumping System Cummins PT Pump
Emission Standard Tier/Euro III
Tail Gas Retreatment
Cummins diesel engine KTTA50-C1600 technique specification
Egnine Cylinder Type 16 Cylinders, V Type
Bore and Stroke 159mm*159mm
Compression Ratio 13.9 : 1
Displacement Type 50L
Fuel Consumption Max 258kg/h at rated power
Air Intake Method Type Turbochager&Intercooled
Engine Size 3200mm*1700mm*2200mm
Weight Net 5700Kgs
Cummins diesel engine KTTA50-C1600 trade information
Warranty Time Basically 1 year or 1500 Hours, please check our warranty terms
Delivary Port Shanghai or any China port
Leading Time 15 working days
Trade Termes FOB/CIF/CNP
Payement termes T/T, L/C

For all new engine, we have warranty term of 1 year or 1000 hours, which one comes first.

All the engine is complete new engine with all necessary accessories: Alternator, starter, Turbocharger, Fuel Pump, Fuel Transfer pump, Water pump, Lub oil pump and filters.

Yes, We could supply the Power pack according your requirement. For example:

Industrial engine—Radiator, Fan, Muffler, Elbow, air filter, air compressor, PTO ect.

Marine engine—Remote Controller and wiring, Gearbox and Coupling.

G-power Engine—Alternator, Controller system.

Vehicle Engine—PTO, Air Compressor, Fan, Radiator, Power steering pump.

Yes, the engine if we quoted as Genuine engine, means the engine is manufactured by China Cummins Plants(DCEC-Dongfeng Cummins Engine Company, CCEC-Chongqing Cummins Engine Company, BFCEC-Beijing Foton Cummins Engine Company and XCEC-Xi’an Cummins Engine Company, GCEC:Guangxi Cummins Engine Company).

Certificate of Conformity, Operation and Maintenance Manual, Notice and nameplate etc.

Additional files for automobile engine: Rubbing paper for license plate application.

Additional files for marine engine: Certificate CCS/IMO

Yes, normally all the genuine parts are under the warranty from the brand owner, in some cases, we offer a warranty under our own company, but this warranty covers only the goods, not the service.
