KTA50-C1600, Engineering K50 Series

Engine model KTA50-C1600

Cummine KTA50-C1600

Engine type 16 Cylinders, V Type
Displacement 50 L
Rated Power 1195kW/1600 HP @ 2100 rpm
Peak Torque 4400 lbs. ft.@1500 rpm
Emission Standard Euro III

Cummins diesel engine KTA50-C1600 Technique Specification
Bore*stroke 159mm*159mm
Intake method Turbochager&Intercooled
Fuel systeme Injection Direct
Cooling method Fluid Cooling
Governor Type Mechanical Control
Compression Ratio 13.9 : 1
Idle Speed 725 r/min
Starting System Electrical Starting Motor 12V/24V
Lowest Starting Temp .(without auxiliary system) -12
Cummins diesel engine KTA50-C1600 Trade Information
Warranty time 1year or 1500h
Engine Size(L*W*H):
Weight net
Delivary port Shanghai
Delivary time 30 working days
Trade termes FOB/CIF/CNP
Payement termes T/T ,  L/C
